HDPE Pipe Extrusion Machine

The high speed HDPE Pipe Extrusion Machine adapts the optimized longer L/C ratio screw,applied on PPR,PE and formulation materialextrusion,has advantages on low wearing,low energy consumption, high efficiency,uniform and stable extrusion.

Send Inquiry

Product Description

Main technical charateristics

The high speed HDPE Pipe Extrusion Machine adapts the optimized longer L/C ratio screw,applied on PPR,PE and formulation materialextrusion,has advantages on low wearing,low energy consumption,

high efficiency,uniform and stable extrusion.

The optimized Siemens computer control system realizes the automatic control of the completely line.The top electricalpneumatic control components ensure the reliable control accuracy and service life.

The special temperature control system of PID high-efficiency extruder ensures

the temperature control precision ofeach heating zone,and ensures the good finish product products.Transmission system upgraded to ensure the durability of the machine and stable production.

HDPE Pipe Extrusion Machine Main technical parameters

model	Screw parameter(mm)	Driving power(kw)	Heating power	Max extrusion volume(kg/h)	Application material
EC60/38	60/38	55	25	220	PE/PPR
EC60/38	60/38	75	25	300	PE/PPR
EC60/38	60/38	90	25	360	PE/PPR
EC60/38	60/38	110	25	440	PE/PPR
EC75/38	75/38	132	30	520	PE/PPR
EC75/38	75/38	160	30	640	PE/PPR
EC90/38	90/38	250	42	1000	PE/PPR
EC90/38	90/38	280	42	1100	PE/PPR
EC120/38	120/38	355	56	1300	PE/PPR
