WPC PVC Ceiling Panel Extruder Machine Line

WPC PVC Ceiling Panel Extruder Machine Line is used to produce PVC wall panel with width normally from 250mm to 300mm with different section shape and height,the surface of PVC ceiling panel can be trested by double by hot stamping printing,or by lamination,which can make marble,wooden design on surface of product.

Send Inquiry

Product Description

WPC PVC Ceiling Panel Extruder Machine Line is used to produce PVC wall panel with width normally from 250mm to 300mm with different section shape and height,the surface of PVC ceiling panel can be trested by double by hot stamping printing,or by lamination,which can make marble,wooden design on surface of product.

WPC PVC Ceiling Panel Extruder Machine Line

WPC PVC Ceiling panel Extruder machine line Featrues

The Plastic PVC door panel board extruder making machine is designed for door making with conical double-screw extruder .The raw  material of wpc door making machine is composed of wood powder ,pvc powder,CaCo3 powder and other additive. PVC wpc door making machine also can produce other kinds of profile, for example, window, door and door frame, pallet, cladding of outdoor wall, facility of outside park, floor etc just need to change the mould and other machine part.

WPC PVC Ceiling Panel Extruder Machine Line

WPC PVC Ceiling panel Extruder machine line parameter

model

YF600

YF800

YF1000

YF1250

Max. Width of product

600

800

1000

1250

Extruder model

SJZ-80/156

SJZ-80/156

SJZ-92/188

SJZ-92/188

Max extruder capacity(kg/h)

280

280

450

450

Extruder power

55

55

110

132

Cooling water consumption(m3/h)

12

13

15

18

Compressed air consumption(m3/h)

0.5

0.6

0.8

1

WPC PVC Ceiling Panel Extruder Machine Line Application

WPC PVC Ceiling Panel Extruder Machine Line
