PET Bottle Recycling Machine Line
  • PET Bottle Recycling Machine Line - 0 PET Bottle Recycling Machine Line - 0
  • PET Bottle Recycling Machine Line - 1 PET Bottle Recycling Machine Line - 1

PET Bottle Recycling Machine Line

Kangju's PET Bottle Recycling Machine Line is customizable based on the contamination level of PP PE films/bags, thereby ensuring the excellence of the end product. By integrating the production line with the following processing steps (granulation system), it efficiently transforms waste and soiled PP PE films/bags into reusable PP PE granules, paving the way for crafting fresh PP PE products.

Send Inquiry

Product Description

PET Bottle Recycling Machine Line

Describe:

Material: Plastic PP PE film/PP PE woven bag/HDPE LDPE PP pet bottle/nylon bag

Product size: 30-100mm or customized

Moisture content: <3%


main feature:

Machine specifications:Capacity (kg/hour)3005001000 Crusher motor (kW)304555 Total power (kW)120150250 Moisture contentless than 3%less than 3%less than 3%Total length (meters)202638 Process flow:

♦ Belt Conveyor : Convey dirty plastic films or bags into the crusher. If you have a lot of scrap metal, you may need a metal detector.

♦ Crusher : It can be crushed with water to cut the plastic film or bag into small pieces.

♦ Screw loader : Load the film sheets into the next step

♦ High-speed friction washing machine : washes away sand, mud and loads materials

♦ Cleaning tank : Separates sand, soil and other dirt

♦ S queezing dryer/horizontal dehydrator/press drying granulator : remove water from materials

1. The entire production line is designed for crushing, washing, dehydrating, and drying PP and PE films.

2. This line boasts a straightforward design, ease of operation, high processing capacity, energy efficiency, as well as safety and dependability.

3. Featuring automatic control throughout the entire line, its structure is neatly organized, ensuring efficient production and optimal cleanliness.

4. Its production capability ranges from 100 to 3000 kilograms per hour.


Main machine list

name (kilowatt)Motor Power (mm)size (T/H)Water Consumption (mm)stainless steel standard electrical standards
Belt conveyor 1.5kW 4000*600*2100mm - - According to customer's standards
Crusher 37kW 1800*1500*3000mm 0.6-1.0 -
spiral charger 1.5kW 3300*420*1600mm - 3-5
Belt conveyor 1.5kW 4000*600*2100mm - -
Crusher 37kW 1800*1500*3000mm 0.6-1.0 -
spiral charger 1.5kW 3300*420*1600mm - 3-5
floating sink 2.2*2KW 6000*1250*1700mm 4-5 3-5
spiral charger 1.5kW 3000*420*1450mm - 3-5
High speed friction washing machine 22kW 3200*1200*1800mm 1-2 3-5
spiral charger 1.5kW 3000*420*1460mm - 3-5
Dehydrator 45kW 1750*1420*1770mm - 5
Drying system-1 28kW 3700*1000*2000mm - 3-5
Transitional storage - 1200*1000*3000mm - -
Drying system-2 28kW 3700*1000*2000mm - 3-5
Storage hopper 2.2kW 3700*1500*3500mm - -
Electrical cabinet - 2000*450*1780mm - -
